These profiles that are in C form, can be manufactured using alloy steel via cold drawing operation. Jib Crane bases are mounted with the anchoring materials to factory floor. Lifting capacity , the lenght of the jib and the height of pillar can be adjusted according to customer's requirement. Jib lenght can be done up to 8 mt. within 30 kg lifting capacity and up to 6 mt. within 1000 kg. lifting capacity.

	Weight Model Jib ( A ) mm Column ( H ) mm Jib bottom height ( C ) mm Natsu CEE Profile No 30 Kg PP11.0030.03 3000 3000 2500 23 PP11.0030.04 4000 3000 2500 23 PP11.0030.05 5000 3000 2500 24 PP11.0030.06 6000 3000 2500 24 PP11.0030.07 7000 3000 2250 24 PP11.0030.08 8000 3000 2250 24 75 Kg PP11.0075.03 3000 3000 2500 24 PP11.0075.04 4000 3000 2500 24 PP11.0075.05 5000 3000 2500 25 PP11.0075.06 6000 3000 2250 25 PP11.0075.07 7000 3000 2250 25 PP11.0075.08 8000 3000 2250 25 125 Kg PP11.0125.03 3000 3000 2500 25 PP11.0125.04 4000 3000 2500 25 PP11.0125.05 5000 3000 2250 25 PP11.0125.06 6000 3000 2250 25 PP11.0125.07 7000 3000 2250 26 PP11.0125.08 8000 3000 2250 26 250 Kg PP11.0250.03 3000 3750 3000 25 PP11.0250.04 4000 3750 3000 25 PP11.0250.05 5000 3750 3000 26 PP11.0250.06 6000 3750 3000 26 PP11.0250.07 7000 3900 3000 26 500 Kg PP11.0500.03 3000 3750 3000 26 PP11.0500.04 4000 3750 3000 26 PP11.0500.05 5000 3900 3000 27 PP11.0500.06 6000 3900 3000 27 PP11.0500.07 7000 4000 3000 27 1000 Kg PP11.1000.03 3000 3900 3000 27 PP11.1000.04 4000 4000 3000 27 PP11.1000.05 5000 4000 3000 27 PP11.1000.06 6000 4000 3000 27
